Technical Specs
| Specs |
Standard |
Metric |
| Length |
36.21 IN |
919.79 MM |
| Height |
11.74 IN |
298.13 MM |
| Width |
10.5 IN |
266.7 MM |
| Weight Excluding Battery |
52.75 LBS |
23.92 KG |
| Weight Including Battery M18 9ah |
55.08 LBS |
24.98 KG |
| Weight Including Battery 20V/60V 9ah FLEXVOLT |
55.95 LBS |
25.37 KG |
| Weight Including Battery 18V LXT 6ah |
54.25 LBS |
24.6 KG |
| Max. Spread Distance |
17 IN |
431.80 MM |
| Max. Spread Force |
286,000 LBS |
1,272 KN |
| Max. Blade Opening |
10.12 IN |
257.06 MM |
| Max. Cut Reach |
5.55 IN |
140.96 MM |
| Max. Cut Force |
156,000 LBS |
694 KN |
| NFPA CUT TEST |
A8, B7, C8, D8, E9, F5 |
|
| Power Source |
18 Volt Milwaukee Battery / 20V DeWalt Battery / 18Volt Makita Battery |
|
| CERTIFIED TO NFPA 1960-2024 |
Yes |
|
| IP RATING |
54 |
