Technical Specs
| Specs |
Standard |
Metric |
| Closed Length |
25.50 IN |
647.7 MM |
| Extended Length |
41.00 IN |
1,041.4 MM |
| Stroke |
15.5 IN |
393.7MM |
| Height |
10.75 IN |
273 MM |
| Width |
8.1 IN |
205.7 MM |
| Weight Excluding Battery |
41.25 LBS |
18.71 KG |
| Weight Including Battery M18 9ah |
43.60 LBS |
19.77 KG |
| Weight Including Battery 20V/60V 9ah FLEXVOLT |
44.45 LBS |
20.16 KG |
| Weight Including Battery 18V LXT 6ah |
42.75 LBS |
19.38 KG |
| Max. Push Force |
37,005 LBS |
164.60 KN |
| Max. Pull Force |
8,293 LBS |
36.88 KN |
| Power Source |
18 Volt Milwaukee Battery / 20V DeWalt Battery / 18Volt Makita Battery |
|
| CERTIFIED TO NFPA 1960-2024 |
Yes |
|
| IP Rating |
54 |
|
