Technical Specs
| Specs |
Standard |
Metric |
| Closed Length |
21.50 IN |
546.1 MM |
| Extended Length |
42.25 IN |
1,073.15 MM |
| Height |
10.75 IN |
273 MM |
| Width |
8.1 IN |
205.7 MM |
| Weight Excluding Battery |
38.75 LBS |
17.57 KG |
| Weight Including Battery M18 9ah |
41.10 LBS |
18.64 KG |
| Weight Including Battery 20V/60V 9ah FLEXVOLT |
41.95 LBS |
19.02 KG |
| Weight Including Battery 18V LXT 6ah |
40.25 LBS |
18.25 KG |
| 1st Stage Stroke |
12.95 IN |
329 MM |
| 1st Stage Push Force |
38,067 LBS |
169.33 KN |
| 2nd Stage Stroke |
8.7 IN |
221 MM |
| 2nd Stage Push Force |
13,088 LBS |
58.21 KN |
| Power Source |
18 Volt Milwaukee Battery / 20V DeWalt Battery / 18Volt Makita Battery |
|
| CERTIFIED TO NFPA 1960-2024 |
Yes |
|
| IR Rating |
54 |
|
