Technical Specs
| Specs |
Standard |
Metric |
| Length |
32.43 IN |
823.77 MM |
| Height |
11.15 IN |
283.09 MM |
| Width |
13.58 IN |
344.93 MM |
| Weight Excluding Battery |
46.85 LBS |
21.25 KG |
| Weight Including Battery M18 9ah |
49.20 lbs |
22.31 KG |
| Weight Including Battery 20V/60V 9ah FLEXVOLT |
50.05 LBS |
22.7 KG |
| Weight Including Battery 18V LXT 6ah |
48.35 LBS |
21.93 KG |
| Max. Spread Distance |
23.5 IN |
596.9 MM |
| Max. Spread Force Range |
64,476 – 242,368 LBS |
286 – 1,078 KN |
| Max. Pull Distance |
18.25 IN |
463.55 MM |
| Max. Pull Force |
14,368 LBS |
63.91 KN |
| Power Source |
18 Volt Milwaukee Battery / 20V DeWalt Battery / 18Volt Makita Battery |
|
| CERTIFIED TO NFPA 1960-2024 |
Yes |
|
| IP Rating |
54 |
|
